When you're building a roll cage, chassis, removable bumper, roof structure, or accessory mount, the connection point is only as strong as the hardware holding it together. That's why interlocking tube disconnect clamps have become a popular solution for builders who need removable tube sections without sacrificing strength.
At Wide Open Design, we've offered interlocking tube disconnect clamps for years, but after bringing manufacturing in-house, we decided it was time to redesign them from the ground up. The result is a stronger, easier-to-install disconnect clamp that solves several common frustrations builders have dealt with for years.
Watch the Full Video
Why Use Interlocking Tube Disconnect Clamps?
Unlike traditional smooth tube clamps that rely solely on bolt clamping force, interlocking tube clamps mechanically lock the two halves together.
This interlocking design helps:
- Increase strength
- Reduce movement between tube sections
- Improve impact resistance
- Better withstand rollovers
- Maintain alignment under load
For off-road vehicles, rock crawlers, rock bouncers, UTV cages, race cars, and custom fabrication projects, an interlocking clamp provides a much stronger connection than a standard smooth-to-smooth disconnect.
The Problem with Previous Designs
One of the biggest complaints we heard from customers involved fitment after powder coating. Many disconnect clamps on the market are machined with extremely tight tolerances. While that may sound good on paper, it often creates problems during assembly. Builders would commonly experience:
- Clamps that were too tight after powder coating
- Bolts that became difficult to start
- Threads binding during installation
- Broken bolts during assembly
- Excessive filing and sanding to make components fit
If you've ever spent time grinding or filing freshly coated parts just to get them together, you know exactly how frustrating that can be.
Redesigned for Real-World Use
When we moved production in-house, we opened up the clamp tolerances by approximately .008" to .010". That small change makes a huge difference. After powder coating, the two clamp halves fit together smoothly while still maintaining the strength and precision needed for demanding off-road applications.
The result is:
- Easier assembly
- Better fit after coating
- Less installation frustration
- No filing or modification required
Captive Nut Design
Another major improvement is the elimination of tapped holes. Instead of threading directly into one side of the clamp, the new design uses a through-bolt and captive nut system. Benefits include:
- Easier installation in tight spaces
- No risk of damaging threaded holes
- Simpler assembly
- Improved serviceability
- Faster removal and reinstallation
- The captive nut is retained inside the clamp body, allowing the bolt to pass straight through from either direction.
For builders working near body panels, plastics, roofs, or interior components, this makes installation significantly easier.
Available for Multiple Applications
Wide Open Design offers disconnect clamps for a variety of fabrication and off-road projects including:
- Roll Cages
- UTV Cages
- Rock Bouncer Chassis
- Rock Crawler Builds
- Removable Bumpers
- Roof Structures
- Engine Cages
- Tire Carriers
- Accessory Mounts
- Custom Fabrication Projects
We also offer a growing selection of:
- Chassis Tabs
- Body Panel Tabs
- Fabrication Brackets
- Weld-On Components
- Builder Kits
All designed to help builders complete projects faster and easier.
Built for Serious Off-Road Abuse
When you're building vehicles that see hard trail use, racing, rollovers, and repeated impacts, connection strength matters.
That's why we continue to recommend interlocking disconnect clamps for critical structural components. The interlocking design creates a stronger mechanical connection than smooth clamps while still allowing sections to be removed when needed.
By bringing production in-house, we were able to improve every aspect of our Interlocking Tube Disconnect Clamps. Better tolerances, easier assembly, captive nuts, and a cleaner installation process all combine to create what we believe is one of the best disconnect clamp options available.
Questions or Comments?
We'd love to hear your thoughts or answer any questions.
