WOD Radiator Mount Brackets for 31" Dual Pass Radiator Combo
F021171
The WOD Radiator Mount Brackets for WA04060 are designed specifically for the WA04060 31" x 15.5" x 3" dual-pass -16 AN radiator and fan shroud combo. The top and bottom brackets wrap around the matching shroud to give builders a clean mounting structure for installing the complete cooling package into a buggy, Jeep chassis, rock bouncer, Ultra4 car, or custom tube chassis.
The brackets support the radiator through the shroud assembly rather than mounting through the radiator core, giving the builder a stronger foundation to tie into the chassis. Laser cut and CNC formed from .100" mild steel, the raw brackets can be welded, modified, tabbed, painted, or powder coated to suit the final cooling-system layout.
Includes:
- (1) Top Radiator / Shroud Mount
- (1) Bottom Radiator / Shroud Mount
- Hardware to Mount Brackets to the WA04060 Radiator & Fan Shroud Assembly
Important: Cooling package sold separately. These brackets are designed only for the WA04060 radiator with its matching fan shroud and are not a universal radiator mount.
Specifications
| Specification | Details |
|---|---|
| Manufacturer | Wide Open Design |
| Part Number | F021171 |
| Product Type | Radiator & Fan Shroud Mounting Bracket Kit |
| Designed For | WA04060 31" x 15.5" x 3" Dual-Pass -16 AN Radiator Combo |
| Material | Mild Steel |
| Material Thickness | .100" |
| Finish | Raw Steel |
| Manufacturing | Laser Cut & CNC Formed |
| Mounting Configuration | Top & Bottom Shroud Mounts |
| Chassis-Side Mounting Hardware | Not Included |
| Weld-On Tabs | Not Included |
| Rubber Isolators / Grommets | Not Included |
| Installation Type | Custom Fabrication Required |
| Cooling Package | Sold Separately |
Fitment
Designed For:
- WA04060 31" x 15.5" x 3" Dual-Pass -16 AN Radiator & Fan Shroud Combo
- Front-mounted radiator installations
- Rear-mounted radiator installations
- Custom tube chassis cooling systems
Common WOD Applications:
- Revolution chassis builds
- Evolution chassis builds
- JC chassis builds
- LJ chassis builds
- JKU chassis builds
- Rock bouncers
- Trail buggies
- Ultra4-style builds
Fitment Notes:
- Fits the WA04060 radiator and matching fan shroud assembly only.
- Does not fit the bare radiator without the matching shroud.
- Does not fit universal radiators based on dimensions alone.
- The included hardware mounts the brackets to the radiator / shroud assembly.
- Final chassis-side tabs, brackets, supports, and mounting hardware must be fabricated for the vehicle.
- Welding and chassis-specific fabrication are typically required.
- Mock up radiator location, airflow, hose routing, fan clearance, and service access before final welding.
FAQ
What radiator do these brackets fit?
These brackets are designed specifically for the WOD WA04060 31" x 15.5" x 3" dual-pass -16 AN radiator when used with its matching fan shroud.
Are these universal radiator brackets?
No. They are purpose-built around the WA04060 radiator and shroud package. A different radiator with similar overall dimensions should not be assumed to fit.
Why do the brackets mount around the fan shroud instead of through the radiator core?
The brackets use the shroud assembly as the mounting structure so the radiator core does not need to carry the chassis mounting load. This gives builders a cleaner foundation for supporting the cooling package in a custom off-road chassis.
Does this kit bolt directly into my chassis?
No. The brackets attach to the WA04060 cooling package, but the final connection to the chassis is builder-specific. Additional tabs, brackets, welding, and fabrication are required based on radiator position and chassis layout.
Can these brackets be used for both front and rear radiator installations?
Yes. The brackets support the WA04060 cooling package itself, so they can be used as the foundation for either front- or rear-mounted radiator layouts as long as the chassis-side mounting structure is fabricated appropriately.
